◆ Applicable media: water, liquid, neutral gas, water vapor.

 ◆ Temperature range: polytetrafluoroethylene: -20℃+ 180℃

 ◆ Ambient temperature: -20℃+ 60℃

 ◆ Viscosity: Max 600mm2/s

 ◆ Installation: any position

 ◆ Flow direction: up/down to the valve seat

 ◆ Control medium: air or neutral gas

 ◆ Control pressure: 0.4MPa-0.8MPa

 ◆ Technical data

 Welding port: Φ19-Φ89

 Valve body: CF8 / CF8M

 Valve seat seal: PTFE

 Valve stem seal: PTFE

 Piston seal: NBR

Each process, each facility, and each environmental constraint has its own special requirements. As a result, Kinko offers a comprehensive range of products that include different performance levels, pressures, functions and materials.
