Technical data

◆ Size: DN15-DN80

◆ Thread: G1/2"-G3

◆ Main material: CF8M

◆ Seat material: Polytetrafluoroethylene

◆ Valve stem material: SS316

◆ Piston sealing ring: Nitrile rubber

◆ Applicable media: Water, liquid, neutral gas, water vapor.

◆ Temperature range: Polytetrafluoroethylene :-20℃+ 180℃

◆ Ambient temperature: -20℃+ 60℃

◆ Viscosity: maximum 600mm ² /s

◆ Installation: Anywhere

◆ Flow direction: Up/down the valve seat

◆ Control medium: Air or neutral gas

◆ Control pressure: 0.4MPa-0.8MPa

Each process, each facility, and each environmental constraint has its own special requirements. As a result, Kinko offers a comprehensive range of products that include different performance levels, pressures, functions and materials.
